CADEX GX Handlebar

Built for maximum speed and control on challenging gravel terrain, the all-new one-piece molded CADEX GX handlebar is designed for those who favor the added confidence of a more aggressive flare in the drops. The extended 16-degree flare combined with an increased 5-degree out and backsweep and D-shaped top section delivers the perfect combination of cockpit compliance and control.
Current price: $539.99
Item # {{ partnumber.code }}

{{partnumber.supplementaryGroup.introText}} {{partnumber.supplementaryGroup.urlLabel}}

{{partnumbersByColor()[0].description}}{{partnumbersByColor()[0].globalFrameSize}}

{{partnumbersByColor()[0].priceToFormat}}

{{partnumbersByColor()[0].stock.Label}}

Expected in our warehouse around {{partnumber.stock.DateExpectedToFormat}}  and shipped to any Cadex retailer in about 1 week{{partnumber.stock.DateExpectedToWeeks}}-{{partnumber.stock.DateExpectedToWeeks + 1}} weeks

The product you have selected is currently out of stock in our warehouse.

Currently in-stock at these Cadex retailers (distance from {{ dealercity }}):
Retailers cannot ship/transfer product, it must be picked up at the locations listed below.
Or it is currently available in-store at the following Cadex retailer(s) near {{ dealercity }}:

  • {{ item.Name | limitTo : 22 }}{{item.Name.length > 22 ? '..' : ''}}

    {{item.Name}}

    {{ item.DistanceToFormat }} KM | {{ item.City }} {{ item.State }}
    Show details Hide details

    {{item.Street}}
    {{item.Zipcode}} {{item.City}}
    Phone: {{item.Phone}}
    {{ item.Email }}
  • No stores found
Show more Find more stores

Please note: {{partnumber.shippingcosts}} shipping fee applies when the bike is shipped from Giant's warehouse

Notify me when available at any Giant retailer

Currently in-stock at these Cadex retailers more than 25 kilometers from {{ dealercity }}. Pick up at these retailers and save the shipping. {{partnumber.shippingCosts}}

Show retailers that have this size in store now

Get free ground shipping on gear orders

Ask us!

Locate an authorized retailer near you!

Features

  • 16-degree flare and 5-degree outsweep provide maximum control over rough, loose gravel and dirt
  • 70mm reach and shallow 115mm drop allow quick and controlled transitions between the tops, the hoods and the drops
  • D-Shaped tops add increased compliance and greater hand comfort for long rides over uneven surfaces
  • 5-degree backsweep offers a more natural hand position for more comfort and balance while climbing
  • Extended 40mm tails add stability and leverage in the drops for increased confidence when sprinting or descending
  • One-piece, no-bond mold manufacturing with T800 and T1100 carbon lamination reinforcement offer featherweight without compromising on strength and stiffness
  • Precision carbon fiber layup provides added strength and weight savings
    Compatible with Shimano Di2 Bar End Type Junction (EW-RS 910)

Specifications

Material
Carbon
Clamp Diameter
31.8mm
Width (hood to hood)
400mm / 420mm / 440mm / 460mm
Width (end to end)
466mm / 486mm / 506mm /526mm
Flare
16 degrees
Out Sweep
5 degrees
Back Sweep
5 degrees
Drop:
115mm
Reach
70mm
Weight
185g (400mm) / 190g (420mm) / 195g (440mm) / 200g (460mm)
Intended Usage

Technologies

CADEX D-Shaped Tops

D-Shaped tops add increased compliance and greater hand comfort for long rides over uneven surfaces

CADEX One Piece Mold Manufacturing

One-piece, no-bond manufacturing utilizes high-grade carbon fiber and CADEX precision layup technique to eliminate the added weight and flex found in traditionally bonded bars.

CADEX Precision Reinforced Layup

CADEX precision reinforced layup places high tensile strength carbon fiber only where needed, creating a strong, stiff structure at minimal weight.
